CENTURY 288 CONDENSER FAN MOTOR
TTD 1,097.00
Century Refrigeration Motor
Speed: 1500 RPM
Power Supply: 230V 1PH 50W 50/60HZ
Part#: 288
- OEM Direct Replacement Motor
- Unit Bearing
- Shaded Pole
- Thermally Protected
- Totally Enclosed Air Over
- Class A Insulation, 40°C Ambient
- Bearing - Unit
- 3/8" Diameter Shaft with Flat
- 34" Leads
- Tapped Double Boss, 3 Tapped Holes Opposite Shaft End
CENTURY 289 CONDENSER FAN MOTOR
TTD 1,013.00
Century Refrigeration Motor
Speed: 1500 RPM
Power Supply: 115V 1PH 50W 50/60HZ
Part#: 289
- OEM Direct Replacement Motor
- Unit Bearing
- Shaded Pole
- Thermally Protected
- Totally Enclosed Air Over
- Class A Insulation, 40°C Ambient
- Bearing - Unit
- 3/8" Diameter Shaft with Flat
- 34" Leads
- Tapped Double Boss, 3 Tapped Holes Opposite Shaft End
CENTURY 9722 CONDENSER FAN MOTOR
TTD 636.00
Century MULTIFIT® Condenser Fan Motor
Speed: 1075 RPM, 1 Speed
Horsepower: 1/8-1/10-1/12 HP
Power Supply: 208-230V, 1 PH, 60 Hz
Part#: 9722
- MultiFit - Condenser Fan Motor
- 5" Diameter - 42 Frame
- Permanent Split Capacitor (PSC); Capacitor Required: 5 Mfd-440 Volts (Not Supplied with Motor)
- Thermally Protected
- Totally Enclosed Air Over
- Class F Insulation, 60°/70°C Ambient
- Ball Bearing
- 1/2" Diameter Shaft with Flat
- 36" Leads
- Multi-Mounting System™ (4.33, 4.42, 4.62 Bolt Circle), Extend Studs Shaft End and Opposite Shaft End
CENTURY 9723 CONDENSER FAN MOTOR
TTD 675.00
Century MULTIFIT® Condenser Fan Motor
Speed: 1075 RPM, 1 Speed
Horsepower: 1/4-1/5-1/6 HP
Power Supply: 200-230V, 1PH, 60 Hz
Part#: 9723
- MultiFit - Condenser Fan Motor
- 5" Diameter - 42 Frame
- Permanent Split Capacitor (PSC); Capacitor Required: 7.5 Mfd-440 Volts (Not Supplied with Motor)
- Thermally Protected
- Totally Enclosed Air Over
- Class F Insulation, 60°/70°C Ambient
- Ball Bearing
- 1/2" Diameter Shaft with Flat
- 36" Leads
- Multi-Mounting System™ (4.33, 4.42, 4.62 Bolt Circle), Extend Studs Shaft End and Opposite Shaft End
CENTURY H697V1 CONDENSER FAN MOTOR
TTD 3,952.00
Century Condenser Fan Motor
Speed: 1200 RPM, 1 Speed
Horsepower: 1.5, 3HP
Power Supply: 200-230/460V, 1Ph, 60 Hz
Part#: H697V1
- Automatic reset thermal protector prevents overheating.
- Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
- Ambient temperature up to 70°C allows for consistent operation in a range of environments and applications.
- Vertical/horizontal mounting for proper placement of the fan within airflow.
- Operational at 200-230/460 V @60HZ. Nameplate image may vary from actual product.
CENTURY FY3156 CONDENSER FAN MOTOR
TTD 4,272.00
Century Condenser Fan Motor
Speed: 1200 RPM, 1 Speed
Horsepower: 1.5HP
Power Supply: 200-230/460V, 3Ph, 60 Hz
Part#: FY3156
- Automatic reset thermal protector prevents overheating.
- Patented MAXGuard® insulation system offers superior protection for use with a variable frequency drive.
- Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
- Ambient temperature up to 70°C allows for consistent operation in a range of environments and applications.
- Vertical/horizontal mounting for proper placement of the fan within airflow.
1383A A.O. Smith Rain Shield for Condenser Fan Motor
TTD 101.00
A.O. SMITH 5/8" CONDENSER FAN MOTOR RAIN SHIELD, PART# 1383A
FC3107 A.O. Smith Condenser Fan Motor
TTD 3,656.00
A.O. SMITH 1HP 1120RPM 200-230V/460V 3PH 60HZ COUNTER CLOCKWISE/ CLOCKWISE CONDENSER FAN MOTOR 5/8" X 4" SHAFT 48Y/56Y FRAME MODEL# FC3107
FE1016SF A.O. Smith Condenser Fan Motor
TTD 844.00
A.O. SMITH 1/6HP 1075RPM 208~230V 60Hz 1PH CW/CCW 48Y FRAME CONDENSER FAN MOTOR MODEL# FE1016SF
FE1016S A.O. Smith Condenser Fan Motor
TTD 703.00
A.O. SMITH 1/6 HP 1075RPM 208V-230V 1PH 60HZ CW/CCW ROT. 1/2" X 6" SHAFT 48Y FRAME CONDENSER FAN MOTOR MODEL# FE1016S
