Condenser Fan Motors

Coldwave Condenser Fan Motor
Part#: 202400420259

Coldwave Condenser Fan Motor
Part#: 202400401434

Coldwave Condenser Fan Motor
Part#: 1501542103

Coldwave Condenser Fan Motor
Part#: 15013067

Coldwave Condenser Fan Motor
Part#: 1501603901

LG Motor Assembly, DC, Outdoor
Part#: EAU43080040

Century HEATMASTER® Condenser Fan Motor
Speed: 1075 RPM, 1 Speed
Horsepower: 4/5HP
Power Supply: 200-230/460V, 1Ph, 60 Hz
Part#: FC1086F

• HeatMaster - Commercial Condenser Fan Motor - Fan Canopy
• 5.6" Diameter - 48 Frame
• Permanent Split Capacitor (PSC); Capacitor Required: 20 Mfd-370 Volts (Not Supplied with Motor)
• Thermally Protected
• Open Air Over
• Class F Insulation, 70°C Ambient
• Ball Bearing
• 1/2" Diameter Shaft with Double Flat, Supplied with 5/8" adapter and Key
• Conduit Box
• Vertical Shaft Up, Belly Band Mount (Belly Band Not Included)

Century Condenser Fan Motor
Speed: 1200 RPM, 1 Speed
Horsepower: 1HP
Power Supply: 200-230/460V, 3Ph, 60 Hz
Part#: FY3106

• Automatic reset thermal protector prevents overheating.
• Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
• Ambient temperature up to 70°C allows for consistent operation in a range of environments and applications.
• Vertical/horizontal mounting for proper placement of the fan within airflow.

Century Condenser Fan Motor
Speed: 1550 RPM, 1 Speed
Power Output: 16W
Horsepower: 1/6HP
Power Supply: 230V, 1Ph, 60 Hz
Part#: UB16CWHV12F

• Refrigeration Motor
• Unit Bearing
• Shaded Pole
• Thermally Protected
• Totally Enclosed Air Over
• Class B Insulation, 40°C Ambient
• Bearing - Unit
• 1/4 x 20 Threaded Shaft
• 28"  Leads with .05" Strip
• 2 Mounting Feet, 3 Rear Mounting Holes

Century Condenser Fan Motor
Speed: 1550 RPM, 1 Speed
Power Output: 16W
Horsepower: 1/6HP
Power Supply: 230V, 1Ph, 60 Hz
Part#: UB16CCHV12F

• Refrigeration Motor
• Unit Bearing
• Shaded Pole
• Thermally Protected
• Totally Enclosed Air Over
• Class B Insulation, 40°C Ambient
• Bearing - Unit
• 1/4 x 20 Threaded Shaft
• 28"  Leads with .05" Strip
• 2 Mounting Feet, 3 Rear Mounting Holes
