DANFOSS 023Z0030 HERMETIC FILTER DRIER
Danfoss Hermetic Filter Drier 023Z0030
Inlet connection type: Solder, ODF
Outlet connection type: Solder, ODF
Core Size code: 30 cu.in.
International Delivery (Outside of Trinidad & Tobago)
We deliver worldwide via courier or freight forwarder.
Most orders are shipped with UPS or DHL. If you have an account with a specified courier, please let us know your account details when you are placing the order.
For larger orders, we ship via ocean freight with our freight forwarder.
Delivery within Trinidad & Tobago)
All orders within Trinidad & Tobago will be delivered either by our in-house delivery service or via TTPost. Delivery is usually fulfilled locally within 0-2 business days.
For orders placed after 7am, delivery will be fulfilled on the following business day.
For orders placed before 7am, it’s possible that we can accommodate same-day delivery as our driver usually leaves our warehouse for daily deliveries between 7-8am.
If you require an item urgently, do let us know. We will do our best to accommodate your needs.
Returns
We do not facilitate international returns.
For local returns, only items returned within 14 days of their original shipment date in same as new condition and in the original packaging will be eligible for a refund or store credit with the original receipt. Restocking & sanitization fees will be charged upon return.
Help
Give us a shout if you have any other questions and/or concerns.
Email: info@servair.com
Phone:1(868)-658-1910 / 1911 / 2010
Product Details
|
Gross weight |
1.382 Kg |
|
Net weight |
1.262 Kg |
|
Volume |
2.268 Liter |
|
EAN |
5702428160032 |
|
Acid capacity [g] |
6.23 g |
|
Acid capacity [oz] |
0.22 oz |
|
Activated alum/Molec sieve [%] |
20% / 80% |
|
Activated alumina [%] |
20 % |
|
Approval |
UL |
|
Body material |
Steel |
|
Braket |
No |
|
Brand |
ELIMINATOR |
|
China RoHS compliance |
Yes exceed limitations |
|
Connection material |
Copper |
|
Core |
Solid core |
|
Core Size code |
30 cu.in. |
|
Core type |
Solid core |
|
Drying Cap[Drops of Water]24°C |
R134a: 888 |
|
Drying Cap[Drops of Water]52°C |
R134a: 813 |
|
EU RoHS compliance |
Yes with exemptions |
|
EU RoHS exemption clause |
6(a) |
|
Filter application |
Std Moisture & Acid Capacity |
|
Flow capacity [kW] |
R134a: 19.3 |
|
Flow capacity [TR] |
R134a: 5.5 |
|
Flow direction indicator |
Label printed 1-way arrow |
|
Fluid Group |
2 |
|
In scope of WEEE and contain batteries |
No |
|
Inlet 1 connection size [in] |
3/8 in |
|
Inlet connection type |
Solder, ODF |
|
LiqCap Cond (ARI 710-2009)[SI] |
Delta p=0.07bar |
|
LiqCapCond (ARI 710-2009)[IMP] |
Delta p=1psi |
|
Lubricants compatibility |
Oilfree applications |
|
Max. Working Pressure [bar] |
46 bar |
|
Max. Working Pressure [psig] |
667 psig |
|
Molecular sieve [%] |
80 % |
|
Net volume [foz US] |
15.68 Fluid Ounce US |
|
Net volume [l] |
0.464 L |
|
Oil free refrigerants |
R1234ze(E) |
|
Outlet 1 connection size [in] |
3/8 in |
|
Outlet connection type |
Solder, ODF |
|
Packing format |
Multi pack |
|
PED category |
Art. 4, par. 3 |
|
Product accessories |
No |
|
Product description |
Liquid line filter drier |
|
Product group |
Filter driers |
|
Product Name Description |
Hermetic filter drier |
|
Quantity per packing format |
8 pc |
|
REACH Candidate List substances |
No |
|
Refrigerants |
R1233zd(E) |
|
Serviceable |
No |
|
Shell volume [foz US] |
24.42 Fluid Ounce US |
|
Shell volume [l] |
0.72 L |
|
Solid core surface [cm2] |
340 cm² |
|
Solid core surface [in2] |
52.7 in² |
|
Solid core volume [cm3] |
258 cm³ |
|
Solid core volume [in3] |
15.77 in³ |
|
Temperature range [°C] [max] |
70 °C |
|
Temperature range [°C] [min] |
-40 °C |
|
Temperature range [°F] [max] |
160 °F |
|
Temperature range [°F] [min] |
-40 °F |
|
Type |
DCL |
|
Type designation |
DCL 303S |
|
UK RoHS compliance |
Out of scope |
|
UL approval file name |
SA6398 |
|
UL approved refrigerants |
R125 |
| Brand | Danfoss |
|---|
