DANFOSS 009L8054 BALL VALVE
Danfoss Ball Valve 009L8054
Inlet connection type: Solder, ODF
Outlet connection type: Solder, ODF
Inlet size [in]: 3/4 in
Outlet size [in]: 3/4 in
International Delivery (Outside of Trinidad & Tobago)
We deliver worldwide via courier or freight forwarder.
Most orders are shipped with UPS or DHL. If you have an account with a specified courier, please let us know your account details when you are placing the order.
For larger orders, we ship via ocean freight with our freight forwarder.
Delivery within Trinidad & Tobago)
All orders within Trinidad & Tobago will be delivered either by our in-house delivery service or via TTPost. Delivery is usually fulfilled locally within 0-2 business days.
For orders placed after 7am, delivery will be fulfilled on the following business day.
For orders placed before 7am, it’s possible that we can accommodate same-day delivery as our driver usually leaves our warehouse for daily deliveries between 7-8am.
If you require an item urgently, do let us know. We will do our best to accommodate your needs.
Returns
We do not facilitate international returns.
For local returns, only items returned within 14 days of their original shipment date in same as new condition and in the original packaging will be eligible for a refund or store credit with the original receipt. Restocking & sanitization fees will be charged upon return.
Help
Give us a shout if you have any other questions and/or concerns.
Email: info@servair.com
Phone:1(868)-658-1910 / 1911 / 2010
Product Details
|
Gross weight |
0.467 Kilogram |
|
Net weight |
0.394 Kilogram |
|
Volume |
0.795 Liter |
|
EAN |
5702428514705 |
|
Access port |
Yes |
|
Approval |
CE |
|
Body material |
Brass |
|
Category |
Art. 4, par. 3 |
|
China RoHS compliance |
Yes exceed limitations |
|
Connection material |
Copper |
|
Cv value [gal/min] |
25.35 gal/min |
|
Direction |
Straightway |
|
EN13463-3 ignit. source assess |
Yes |
|
Equipment |
Cap w. wire seal |
|
EU RoHS compliance |
Yes with exemptions |
|
EU RoHS exemption clause |
6(c) |
|
Flow direction |
Bi-flow |
|
Flow direction indicator |
Embossed 2-way arrow |
|
Fluid Group |
1 |
|
In scope of WEEE and contain batteries |
No |
|
Inlet connection type |
Solder, ODF |
|
Inlet size [in] |
3/4 in |
|
Kv value [m³/h] |
21.93 m³/h |
|
Max. media temp. Oil free [°C] |
80 °C |
|
Max. Working Pressure [bar] |
45 bar |
|
Max. Working Pressure [psig] |
650 psig |
|
Oil free refrigerants |
R1234ze(E) |
|
Outlet connection type |
Solder, ODF |
|
Outlet size [in] |
3/4 in |
|
Packing format |
Multi pack |
|
Parts included |
Schrader valve |
|
Product accessories |
BM/GBC valve accessories |
|
Product group |
Shut-off and regulating valves |
|
Product Name Description |
Shut-off ball valve |
|
Quantity per packing format |
25 pc |
|
Refrigerants |
R1234yf |
|
Serviceable |
BM/GBC valve spare parts |
|
Temperature range [°C] [Max] |
100 °C |
|
Temperature range [°C] [Min] |
-40 °C |
|
Temperature range [°F] [Max] |
212 °F |
|
Temperature range [°F] [Min] |
-40 °F |
|
Type |
GBC 18s |
|
UK RoHS compliance |
Out of scope |
|
UL approved refrigerants |
R1234yf |
