DANFOSS 060-5246 PRESSURE SWITCH
Danfoss Pressure Switch 060-5246
Regulation range [bar] Pe: 8.00 - 42.00
Contact function: SPDT
Reset function: Manual Max
Pressure connection type: Flare nut
Pressure connection size: 1/4
Pressure Male/Female: Female
Enclosure rating IP: IP30
Max. Working Pressure [bar]: 46.5
International Delivery (Outside of Trinidad & Tobago)
We deliver worldwide via courier or freight forwarder.
Most orders are shipped with UPS or DHL. If you have an account with a specified courier, please let us know your account details when you are placing the order.
For larger orders, we ship via ocean freight with our freight forwarder.
Delivery within Trinidad & Tobago)
All orders within Trinidad & Tobago will be delivered either by our in-house delivery service or via TTPost. Delivery is usually fulfilled locally within 0-2 business days.
For orders placed after 7am, delivery will be fulfilled on the following business day.
For orders placed before 7am, it’s possible that we can accommodate same-day delivery as our driver usually leaves our warehouse for daily deliveries between 7-8am.
If you require an item urgently, do let us know. We will do our best to accommodate your needs.
Returns
We do not facilitate international returns.
For local returns, only items returned within 14 days of their original shipment date in same as new condition and in the original packaging will be eligible for a refund or store credit with the original receipt. Restocking & sanitization fees will be charged upon return.
Help
Give us a shout if you have any other questions and/or concerns.
Email: info@servair.com
Phone:1(868)-658-1910 / 1911 / 2010
Product Details
|
Gross weight |
0.755 Kilogram |
|
Net weight |
0.72 Kilogram |
|
Volume |
1.151 Liter |
|
EAN |
5702428063753 |
|
Amb. Temp. Note |
80 °C/176 °F for max 120 min |
|
Ambient temperature range [°C] [max] |
50 °C |
|
Ambient temperature range [°C] [min] |
-40 °C |
|
Ambient temperature range [°F] [max] |
122 °F |
|
Ambient temperature range [°F] [min] |
-40 °F |
|
Application note |
Not applicable for liquid line |
|
Approval |
CE |
|
Cap. tube length fraction [in] |
36 in |
|
Capillary tube length [mm] |
900 mm |
|
CE evaluated |
Yes |
|
China RoHS compliance |
Out of scope |
|
Contact function |
SPDT |
|
Contact rating |
144 A, 240 V AC |
|
Differential [psi] |
60 psi |
|
Electrical conn. comments |
for ½ in male pipe thread |
|
Electrical connection |
Hole |
|
Electrical connection size |
7/8 in |
|
EN 60947 electrical properties |
Insulation: 400V |
|
EN 60947 wiring properties |
Flex, ferrules: 0.5-1.5 mm2 |
|
Enclosure rating IP |
IP30 |
|
Enclosure rating Nema (~) |
1 |
|
EU RoHS compliance |
Yes |
|
EU RoHS exemption clause |
No |
|
Fluid Group |
1 |
|
In scope of WEEE and contain batteries |
No |
|
Lubricants compatibility |
Oilfree applications |
|
Max. test pressure [bar] Pe |
50 bar |
|
Max. test pressure [psig] |
725 psig |
|
Max. Working Pressure [bar] |
46.5 bar |
|
Max. Working Pressure [psig] |
675 psig |
|
Oil free refrigerants |
R134a |
|
Packing format |
Multi pack |
|
PED category |
IV |
|
Pressure connection size |
1/4 |
|
Pressure connection standard |
DIN 8912 |
|
Pressure connection type |
Flare nut |
|
Pressure Male/Female |
Female |
|
Pressure sensing element |
Bellows |
|
Product accessories |
Switches accessories |
|
Product description |
High Pressure Control |
|
Product group |
Switches and thermostats |
|
Product Name Description |
Pressure switch |
|
Quantity per packing format |
10 pc |
|
REACH Candidate List substances |
No |
|
Refrigerants |
R113 |
|
Regulation range [bar] Pe [max] |
42 bar |
|
Regulation range [bar] Pe [min] |
8 bar |
|
Regulation range [psig] Pe [max] |
600 psig |
|
Regulation range [psig] Pe [min] |
100 psig |
|
Reset function |
Manual Max |
|
Serviceable |
No |
|
Type |
KPU6B |
|
UK RoHS compliance |
Out of scope |
|
UL approval file name |
E31024 |
|
UL approved refrigerants |
R113 |
|
UL evaluated |
Yes |
